Dolby CP750 Digital Cinema Processor The Latest in Sound Processing - from Dolby Digital Cinema The Dolby® CP750 is equipped to handle the exciting new entertainment opportunities made possible by digital cinema. While it is ideal for new digital only theatres, it is also the best choice when converting a cinema with an existing film processor with the capacity to input to a CP750 for hybrid film and digital installations.
The CP750 is as economical as it is functional. Dolby Surround EX decoding is supplied for content encoded with a back surround channel. In addition, Dolby Pro Logic® and Dolby Pro Logic II can derive surround from stereo content to enhance programming. Your audience will always enjoy outstanding surround sound before, after, and during the show, no matter the program source. To take advantage of new, market expanding programming, the CP750 provides inputs for three additional digital sources as well as your cinema server. The CP750 accepts up to eight PCM channels from any cinema server, supporting access to optional hearing- and visually-impaired tracks.
Three additional digital inputs accept PCM or 5.1-channel Dolby Digital from preshow and alternative content sources. Microphone and analog non-sync inputs round out the CP750's comprehensive connectivity. The Dolby CP750 can be updated, controlled, and monitored remotely via the Internet. A system integrator's NOC, for example, can keep tabs on all its CP750 installations wherever they are by SNMP messaging or remote/setup monitoring software. This unique feature helps to catch problems before they impact your bottom line, ensuring the glitch-free, quality presentations audiences expect. The CP750 is a perfect complement to Dolby's Theatre Management System (TMS) software.
It responds to digital input selection and volume cues within a show, enables real-time volume control from any TMS client, and recognizes ASCII commands from third-party TMS controllers. In sum, the CP750 is easy to integrate and set up for automatic operation. The Dolby CP750 combines robust construction, state-of-the-art hardware and software, practical functionality, and legendary Dolby quality. Whether equipping a single screen, a multiplex, or a large network, the Dolby CP750 is the most logical choice. Front Panel Digital 1 Input 4 × AES 25-pin female D-connector provides four AES/EBU channel pair inputs Input impedance: 110? Balanced Digital 2, 3 Inputs 1 × AES male BNC connectors, unbalanced but floating, per AES-3id-1995/SMPTE 276M Input impedance: 75? New Edition Discography 320Kbps Torrent more.
The Dolby CP750 can be updated. Remote/setup monitoring software. CP750 Digital Cinema Processor Dolby Laboratories, Inc.
Digital 4 Input Optical Toslink connector Multichannel Analog Input Eight-channel 25-pin female D-connector, balanced analog, 10K differential input impedance Reference level: 300 mV Nonsync Input Two-channel RCA connector, 21K input impedance, adjustable input level Microphone Input XLR connector, standard pinout, 10K differential input impedance, 12V phantom power available, adjustable gain Rear Panel Main Audio Output Eight-channel 25-pin male D-connector, balanced floating analog, 100? Differential output impedance Do not load with less than 600? Differential Auxiliary Output Two-channel, unbalanced analog, 100? Output impedance, RCA connectors Reference level: 200 mV Always routes channel pair 7/8 of 4 × AES input for alternate uses such as HI and VI-N transmittersthis fixed-level output has no EQ and is not controlled by the fader Hearing-Impaired Output One-channel, unbalanced analog, 100?
Output impedance, RCA connector Center weighted sum of Left, Center, and Right channels Output level: 200 mV.
